List Price (USD):
Valid in USA and Canada only
JV300-160 Plus: $17,858

Delivers Stunning Quality At Class-Leading Speeds

Grow your business with these roll-based machines that offer increased throughput and a lower cost of operation. Choose eco-solvent inks to create an array of sign and graphic applications. Or dye-sublimation inks for textile, apparel and soft signage production.
  • Available in 64” with print speeds up to 1,140 SqFt/Hr
  • Choice of eco-solvent ink or dye-sublimation ink sets

Eco-solvent: 8 color options including White, Orange and Light Black inks

Dye-sublimation: 6 color options including Light Blue and Light Magenta inks

  • Economical 2-liter bulk ink system for long running jobs
  • Even ink drying with three-way intelligent heater
  • Reusable Mimaki Eco-Cartridge on SS21, BS3 and BS4 eco-solvent inks
  • Automatic media take-up reel
  • USB/Ethernet connectivity
  • RIP software RasterLink6 included

Our Core Technologies


Waveform Control


Mimaki Advanced Pass System


Mimaki Intelligent Heaters


Nozzle Check Unit


Nozzle Recovery System


Mimaki Bulk Ink System


Uninterrupted Ink Supply System


Mimaki Circulation Technology


Mimaki Fine Diffusion

Applications

img img img img img img img img img img

Specifications

Printhead

Two on-demand piezo heads in a staggered array

Print resolution

360dpi, 540dpi, 720dpi, 1,080dpi, and 1,440dpi

Print speed (4 color mode)

JV300-160 Plus: up to 1139.898 SqFt/Hr (105.9 m2/h)

Maximum Print Area

JV300-160 Plus: 63.4″ (1610 mm)

Maximum media width

JV300-160 Plus: 63.8″ (1620 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight

99 lbs. (45 kg)

Ink Type

U.S. & Canada- SS21, ES3, Sb54 | Mexico, Central & South America- SS21, ES3, BS3, BS4, Sb54

Interface

Ethernet, USB 2.0

Power supply

Single-phase (AC100 – 120V / AC200 – 240V) x2

Power consumption

AC100V: 1.44kW or less x2 | AC200V: 1.92kW or less x2

Operational environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

JV300-160 Plus: 109″ x 28″ x 55″ (276.9 x 71.1 x 139.7 cm)

Weight

JV300-160 Plus: 441 lbs. (200 kg)

Certifications

VCCI class A, FCC class A, ETL UL 60950-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM

Inks

Solvent ink (SS21)CyanMagentaYellowBlackLight CyanLight MagentaLight BlackOrangeWhite
2L MBIS Pack*SPC-0588CSPC-0588MSPC-0588YSPC-0588KSPC-0588LCSPC-0588LMSPC-0588LKSPC-0588OR
220ml cartridgeSPC-0504W-2
600ml eco cartridgeSS21-C-60SS21-M-60SS21-Y-60SS21-K-60SS21-LC-60SS21-LM-60SS21-LK-60SS21-OR-60

Eco Solvent ink (ES3)CyanMagentaYellowBlackLight CyanLight MagentaLight BlackOrangeWhite
440ml cartridgeSPC-0440CSPC-0440MSPC-0440YSPC-0440KSPC-0440LCSPC-0440LM
220ml cartridgeSPC-0433W-2

Dye Sublimation ink (Sb54)BlueMagentaYellowBlackLight BlueLight Magenta
2L MBIS Pack*SB54-BLT-2LSB54-MT-2LSB54-YT-2LSB54-KT-2LSB54-LBT-2LSB54-LMT-2L
440ml cartridgeSB54-BLT-44SB54-M-44SB54-Y-44SB54-K-44SB54-LBL-44SB54-LMT-44

Solvent ink (BS3)CyanMagentaYellowBlack
2L MBIS Pack*SPC-0693CSPC-0693MSPC-0693YSPC-0693K
600ml cartridgeSPC-0667CSPC-0667MSPC-0667YSPC-0667K

Solvent ink (BS4)CyanMagentaYellowBlack
2L MBIS Pack*BS4-C-2LBS4-M-2LBS4-Y-2LBS4-K-2L
600ml cartridgeBS4-C-60BS4-M-60BS4-Y-60BS4-K-60

*Inks sold vary by county, see specification chart above for details.

Inks

Solvent ink (SS21)
2L MBIS Pack*
Cyan:
SPC-0588C
Magenta:
SPC-0588M
Yellow:
SPC-0588Y
Black:
SPC-0588K
Light Cyan:
SPC-0588LC
Light Magenta:
SPC-0588LM
Light Black:
SPC-0588LK
Orange:
SPC-0588OR
:
_ _
:
_ _
220ml cartridge
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
White:
SPC-0504W-2
:
_ _
600ml eco cartridge
Cyan:
SS21-C-60
Magenta:
SS21-M-60
Yellow:
SS21-Y-60
Black:
SS21-K-60
Light Cyan:
SS21-LC-60
Light Magenta:
SS21-LM-60
Light Black:
SS21-LK-60
Orange:
SS21-OR-60
:
_ _
:
_ _
*Inks sold vary by county, see specification chart above for details.
Eco Solvent ink (ES3)
440ml cartridge
Cyan:
SPC-0440C
Magenta:
SPC-0440M
Yellow:
SPC-0440Y
Black:
SPC-0440K
Light Cyan:
SPC-0440LC
Light Magenta:
SPC-0440LM
:
_ _
:
_ _
:
_ _
:
_ _
220ml cartridge
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
White:
SPC-0433W-2
:
_ _
*Inks sold vary by county, see specification chart above for details.
Dye Sublimation ink (Sb54)
2L MBIS Pack*
Blue:
SB54-BLT-2L
Magenta:
SB54-MT-2L
Yellow:
SB54-YT-2L
Black:
SB54-KT-2L
Light Blue:
SB54-LBT-2L
Light Magenta:
SB54-LMT-2L
:
_ _
:
_ _
:
_ _
:
_ _
440ml cartridge
Blue:
SB54-BLT-44
Magenta:
SB54-M-44
Yellow:
SB54-Y-44
Black:
SB54-K-44
Light Blue:
SB54-LBL-44
Light Magenta:
SB54-LMT-44
:
_ _
:
_ _
:
_ _
:
_ _
*Inks sold vary by county, see specification chart above for details.
Solvent ink (BS3)
2L MBIS Pack*
Cyan:
SPC-0693C
Magenta:
SPC-0693M
Yellow:
SPC-0693Y
Black:
SPC-0693K
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
600ml cartridge
Cyan:
SPC-0667C
Magenta:
SPC-0667M
Yellow:
SPC-0667Y
Black:
SPC-0667K
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
*Inks sold vary by county, see specification chart above for details.
Solvent ink (BS4)
2L MBIS Pack*
Cyan:
BS4-C-2L
Magenta:
BS4-M-2L
Yellow:
BS4-Y-2L
Black:
BS4-K-2L
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
600ml cartridge
Cyan:
BS4-C-60
Magenta:
BS4-M-60
Yellow:
BS4-Y-60
Black:
BS4-K-60
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
*Inks sold vary by county, see specification chart above for details.
