List Price (USD):
: Call For Pricing

Fashionable Ferocity, Be The Predator Not The Prey!

The Tiger 1800 MkIII digital textile printer combines high productivity with print speeds up to 4,144 ft2/hour and long operational stability. Direct-to-textile and direct-to-transfer (sublimation transfer) models are available. With 10kg ink tanks, customers can choose the print speed that best suits their needs, allowing for longer run-times and lower running costs. This high volume printer enables businesses to focus on productivity and high-quality printing with fine detail, all while achieving smoother colors and transitions.



Garment manufacturers in the textile industry benefit from:
  • NEW printer controller with touchscreen capabilities to operate the unit, output data, select jobs, and check on remaining ink
  • NEW Nozzle Recovery System (NRS) automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality to ensure high-quality textile production
  • NEW MAPS4 minimizes banding and enhances print quality at higher print speeds
  • Ethernet 10GB-T supported to allow for high speed transfer of print data
  • Adhesive belt transport system with belt washing technology and in-line heat drying unit
  • Available as a complete direct-to-textile model or as a paper transfer dye sublimation model
  • TxLink4 Lite supported for more advanced workflows

Our Core Technologies


Waveform Control


Variable Dot Technology


Mimaki Advanced Pass System


Nozzle Recovery System


Mimaki Bulk Ink System

Applications

img img img img img img img img img

Specifications

Printhead

Tiger-1800B MkIII DS: Eight on-demand piezo heads in a staggered array
Tiger-1800B MkIII DTT: Sixteen on-demand piezo heads in a staggered array

Print resolution

1200 dpi

Print Speed (4 Color Mode)

up to 4144.11 SqFt/Hr (385 m2/h)

Maximum Print Area

72.8″ (1850 mm)

Maximum media width

74.8″ (1900 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight

220.7 lbs. (100.0 kg)

Ink Type

Tiger-1800B MkIII DS: U.S. & Canada- MLSb510 | Mexico, Central & South America- MLSb510
Tiger-1800B MkIII DTT: U.S. & Canada- MLRc500 | Mexico, Central & South America- MLRc500

Interface

Ethernet 1000BASE-T, USB2.0 Hi-speed

Power Supply

Main unit: 3 phase 380 V ± 10%, 50 / 60 Hz 50 A or less | Heater: 3 phase 380 V ± 10%, 50 / 60 Hz 30 A or less

Power Consumption

AC400V: Printer – 22 kW or less | Drying and take-up unit – 14 kW or less

Dimensions (W × D × H)

Main: 219 x 81 x 89″ (5,550 x 2,050 x 2,250mm)

Weight

Main unit: 10,582.2 lbs. (4,800 kg)
Drying and take-up unit: 12,645.5 lbs. (1,200 kg)

Certifications

CE Marking (EMC, Machinery directive, and RoHS)

Inks

Reactive Dye Ink (MLRC50)BlueMagentaYellowBlackLight BlackBlueOrangeRed
10kg BottlesMLR50-C-BJMLR50-M-BJMLR50-M-BJMLR50-M-BJMLR50-M-BJMLR50-M-BJMLR50-M-BJMLR50-M-BJ

Dye Sublimation Ink (MLSB510)CyanMagentaYellowBlack
10kg BottlesMLSS1-BLT-BJMLSS1-MT-BJMLSS1-YT-BJMLSS1-K-BJ

Inks

Reactive Dye Ink (MLRC50)
10kg Bottles
Blue:
MLR50-C-BJ
Magenta:
MLR50-M-BJ
Yellow:
MLR50-M-BJ
Black:
MLR50-M-BJ
Light Black:
MLR50-M-BJ
Blue:
MLR50-M-BJ
Orange:
MLR50-M-BJ
Red:
MLR50-M-BJ
:
_ _
:
_ _
Dye Sublimation Ink (MLSB510)
10kg Bottles
Cyan:
MLSS1-BLT-BJ
Magenta:
MLSS1-MT-BJ
Yellow:
MLSS1-YT-BJ
Black:
MLSS1-K-BJ

Contact Mimaki Today

To learn more about the Tiger-1800B MkIII roll-to-roll digital textile printing machine, and how it can improve quality, speed, and detail/color, schedule a demo today. We can discuss additional benefits such as reduction in banding, color shifting, and production delays. Our latest digital textile printer includes everything needed to improve your printing processes. Call 888-530-3988 for more information.
