Expressive prints on a variety of materials

This latex printer is designed for efficient high-quality prints. Latex inks allow printing on media designed for solvent ink, such as PVC, as well as a variety of other materials, including affordable non-treated paper, banner, signage material and more. The ink is fixed and cured right after print, therefore eliminating drying time and increasing turnaround. Mimaki’s latex ink is eco-friendly,water-based and allows for three-layer printing.
  • Maximum print speed of 18.2m 2 /h
  • Excellent for outdoor and indoor applications
  • Eco-friendly latex ink with wide color gamut, includes White ink

Our Core Technologies


Waveform Control (WFC)


Mimaki Advanced Pass System (MAPS)


Mimaki Circulation Technology (MCT)


Uninterrupted Ink Supply System (UISS)


Variable Dot Technology


Mimaki Intelligent Heaters (MIH)


Nozzle Recovery System (NRS)

Applications

img img img img img img img

Specifications

Printhead

Two in-line on-demand piezo heads

Print Resolutions

600, 900, 1200dpi

Print Speed (4 Color Mode)

up to 195.9 SqFt/Hr (18.2 m2/h)

Maximum Print Area

63.4″ (1610.0 mm)

Maximum media width

63.8″ (1620.0 mm)

Maximum Media Thickness

up to 0.00″ (1 mm)

Maximum Media Weight

55.1 lbs. (25.0 kg)

Ink Type

U.S. & Canada- N/A | Mexico, Central & South America- LX101

Interface

USB2.0 Hi-speed

Power Supply

Single phase AC100 – 120V / AC220 – 240V ±10%

Power Consumption

AC100V: 1440W x 2 or less

Operational Environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

113.3″ x 33.6″ x 56.5″ (287.9 x 85.4 x 143.5 cm)

Weight

509.3 lbs. (231 kg)

Certifications

VCCI class A, FCC class A, UL 60950-1 CE Marking (EMC, Low voltage and Machinery directive), CB Report

Latex ink (LX101) CyanMagentaYellowBlackOrangeGreenWhite
600ml cartridge LX101-C-60 LX101-M-60 LX101-Y-60 LX101-K-60 LX101-OR-60 LX101-G-60
220ml cartridge LX100-W-22

Latex ink (LX101)
600ml cartridge
Cyan:
LX101-C-60
Magenta:
LX101-M-60
Yellow:
LX101-Y-60
Black:
LX101-K-60
Orange:
LX101-OR-60
Green:
LX101-G-60
White:
_ _
:
_ _
:
_ _
:
_ _
220ml cartridge
Cyan:
_ _
Magenta:
_ _
Yellow:
_ _
Black:
_ _
Orange:
_ _
Green:
_ _
White:
LX100-W-22
:
_ _
:
_ _
:
_ _

Resources

Specifications

JV400-160LX
