UJV100-160 : $15,995

Productivity And Versatility At An Entry-Level Price

The UJV100-160 is a competitively priced UV-LED roll-based printer with all the productivity features of higher-end models. It features Mimaki instant-dry UV-LED inks that adhere to a variety of media, including paper, PET film, fabric, vinyl, and more, making post-printing handling and finishing effortless. With UV light, UV-LED inks cure instantly, dramatically increasing printing speed and efficiency. This multi-purpose machine is suited for a variety of applications while keeping costs low, and offers:
  • 160 cm width, with print speeds up to 23m2/h
  • High media versatility with unparalleled scratch resistance
  • New Dot Adjustment System (DAS) automates dot position and feeding corrections, reducing manual intervention and workflow interruption
  • Eco-friendly, six color inkset in 1-liter bottles: C, M, Y, K, W, Cl
  • Instantly cured prints for shorter turnarounds and additional cost savings

Our Core Technologies


Mimaki Advanced Pass System (MAPS)


Nozzle Recovery System


Nozzle Check Unit

Applications

art canvas mimaki high resolution banner interior wallpaper mini wrap window decal
The wide range of applications supported include posters, banners, backlit signs, retail signage, vehicle exteriors, artwork, promotional displays, wallpaper, and more. A UV-LED printing machine can work with many different materials, such as plastic, wood, glass, metal, or foam core as well as textiles and leather, allowing limitless applications.

Specifications

Printhead

Two on-demand piezo heads, staggered layout

Print Resolutions

360 dpi, 720 dpi, 900 dpi, 1200 dpi

Print Speed (4 Color Mode)

23 m²/h (Draft), 18.6 m²/h (High Speed)

Maximum Print Area

63.4″ (1610.0 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 1 mm

Maximum Media Weight

up to 45 kg

Ink Type

U.S. & Canada- LUS-170
Mexico, Central & South America- LUS-210: C, M, Y, K, W, CI (Clear ink: availability TBC)

Ink Package Size

1L bottle

Interface

USB2.0 / Ethernet

Power Supply

Single phase AC100 – 120 / 200 – 240V ±10%, 50/60Hz±Hz

Operational Environment

Temperature 20° – 30°C
Humidity: 35 – 65 % RH (Non condensing)

Dimensions (W × D × H)

2775 x 700 x 1392 mm

Weight

167 kg

Options

Ionizer / Level foot / Lift-up block

UV Curable Ink (LUS170)CyanMagentaYellowBlackWhiteClear
1L BottleLUS17-C-BALUS17-M-BALUS17-Y-BALUS17-K-BALUS17-W-BALUS17-CL-BA

UV Curable Ink (LUS210)CyanMagentaYellowBlackWhiteClear
1L BottleLUS21-C-BALUS21-M-BALUS21-Y-BALUS21-K-BALUS21-W-BALUS21-CL-BA

UV Curable Ink (LUS170)
1L Bottle
Cyan:
LUS17-C-BA
Magenta:
LUS17-M-BA
Yellow:
LUS17-Y-BA
Black:
LUS17-K-BA
White:
LUS17-W-BA
Clear:
LUS17-CL-BA
UV Curable Ink (LUS210)
1L Bottle
Cyan:
LUS21-C-BA
Magenta:
LUS21-M-BA
Yellow:
LUS21-Y-BA
Black:
LUS21-K-BA
White:
LUS21-W-BA
Clear:
LUS21-CL-BA

Contact Mimaki

Mimaki offers a full range of UV and other roll-to-roll printers, including the UJV100-160. Contact us at 888-530-3988 with any questions or to schedule your demo today.
