Waveform Control
Mimaki Advanced Pass System
Mimaki Intelligent Heaters
Nozzle Check Unit
Nozzle Recovery System
Mimaki Bulk Ink System
Uninterrupted Ink Supply System
Mimaki Circulation Technology
Mimaki Fine Diffusion
Continuous Mark Detect
Half Cut
Over Cut
Zero Margin Mark
| Printhead | One on-demand piezo print head (single) |
| Print resolution | X: 600,1200 dpi | Y: 600,900,1200 dpi |
| Print speed (4 color mode) | 183 sqft/hr (17 sqm/hr) |
| Maximum Print Area | CJV200-75: 31.5 in (800 mm) CJV200-130: 53.6 in (1361 mm) CJV200-160: 63.4 in (1610 mm) |
| Maximum media width | CJV200-75: 31.9 in (810 mm) CJV200-130: 53.9 in (1371 mm) CJV200-160: 63.8 in (1620 mm) |
| Maximum Media Thickness | up to 0.04 in (1 mm) |
| Maximum Media Weight | 55 lbs. (25 kg) |
| Ink Type | Eco-Solvent inks: SS22 (C, M, Y, K, Lc, Lm, Lk, Or) |
| Interface | USB 2.0 Hi-speed | Ethernet 1000 BASE-T |
| Power Supply | AC (100-120V / 200-240V±10%) × two 50/60Hz±1Hz |
| Power Consumption | Max. 1320W x2 | Sleep mode: 4.5W |
| Operational Environment | Temperature 68° – 86° F (20-30° C) |
| Dimensions (W × D × H) | CJV200-75: 77 in W x 29.5 in D x 54 in H (1960 mm W × 748 mm D × 1370 mm H) CJV200-130: 99 in W x 29.5 in D x 54 in H (2520 mm W ×748 mm D×1370 mm H) CJV200-160: 109 in W x 29.5 in D x 54 in H (2770 mm W x 748 mm D x 1370 mm H) |
| Weight | CJV200-75: 231.4 lbs. (105 kg) CJV200-130: 286.6 lbs. (130 kg) CJV200-160: 308.6 lbs. (140 kg) |
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA |
| Warranty Information* | *The Mimaki Total Care warranty covers any defects in material and workmanship arising from the normal use of the product. Mimaki Total Care includes priority phone support and on-site services with labor and parts. Mimaki Parts Plus+ includes parts and phone support, with billable labor and travel expenses. For the JV/CJV200 Series, the warranty is Mimaki Total Care for year one on the full device, including labor. Years two and three are Mimaki Parts Plus+ covering all non-consumable parts. All three years cover print heads. This warranty is available for products shipped to customers in the United States and Canada. |
| Eco-Solvent ink (SS22) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Light Black | Orange | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 440ml cartridge | SS22-C-44 | SS22-M-44 | SS22-Y-44 | SS22-K-44 | SS22-LC-44 | SS22-LM-44 | SS22-LK-44 | SS22-OR-44 | ||
| 1L Bulk Ink Pack* | SS22-C-1L | SS22-M-1L | SS22-Y-1L | SS22-K-1L | SS22-LC-1L | SS22-LM-1L | SS22-LK-1L | SS22-OR-1L |
| Eco-Solvent ink (SS22) | |
|---|---|
| 440ml cartridge |
|
| 1L Bulk Ink Pack* |
|
