Continuous Mark Detect
Half Cut
Over Cut
Zero Margin Mark
ID Cut
| Type | Roll-based cutting plotter |
| Maximum Media Width | CG-60AR: 29.1″ (740 mm) |
| Cutting Width | CG-60AR: 23.9″ (600 mm) |
| Maximum media thickness | Recommended sheets up to 0.01″ (.25mm) including laminate and liner; Up to 0.04″ (1mm) max (results may vary) |
| Maximum Cut Speed | 28.7″/s (73 cm/s) |
| Moving speed second | 40.5″/s (103 cm/s ) |
| Maximum Cut pressure (Metric grams) | 550g |
| Adjustable speed range | 1-10cm/s: 1cm/s step adjustment |
| Cutter Types | Eccentric cutter, Blade for small character, Blade for reflective sheet, Blade for fluorescent sheet, Blade for PVC with low-pressure, Ball point pen, Cutter heavy paper, Creasing Tool |
| Mechanical resolution | X direction: 2.5 μm; Y direction 5 μm |
| Program steps | 25 μm or 10 μm (MGL-IIc); 100 μm, 50 μm (MGL-Ic1) |
| Repeatability | +/- 0.2 mm / 2 M |
| Downforce pressure | Cutter: 10-20g (2g step), 20-100g (5g step), 100-550g (10g step) |
| Command | MGL-IIc, MGL-Ic1 |
| Interface | USB, RS-232C, Ethernet |
| Receive buffer | 27MB standard, 17MB when sorting |
| Power supply | AC 100 V – 240 V 1A 50/60Hz |
| Power consumption | 168W or less | 228W or less | 228W or less |
| Operational Environment | Temperature: 5 – 35 degC (41 – 95 degF), |
| Dimensions (W × D × H) | CG-60AR: 1,010 × 355 × 355 mm (39.8 × 14.0 × 14.0″) 1,010 × 580 × 1,160 mm *6 CG-130AR: 1,810 × 580 × 1,160 mm (71.3 × 22.8 × 45.7″) |
| Weight | CG-60AR: 37.5 lbs. (17 kg) CG-130AR: 94.8 lbs. (43 kg) |
