List Price (USD):
TS330-1600: $24,995

Scalable Design, High Production

The TS330-1600 fabric and textile printer uses Sb411/Sb410 (Fluo) dye sublimation inks. It is a high grade industrial sublimation printing solution with an expanded fluorescent color range (including fluorescent pink and yellow). Additionally, it allows for unmatched productivity regardless of printing volume, with an impressive printing speed of 1,453 sq ft. per hour.

This sublimation transfer inkjet printer provides superior image quality and employs Mimaki Weaving Dot Technology (MWDT). MWDT adapts to various printing conditions by changing ink drop placement order, allowing more consistent quality and leading to reduced downtime. To help reduce operating costs, an optional 10kg bulk ink system.

This advanced dye sublimation printing system supports production sizes up to 64" and has 4, 6, 7, and 8 color configurations. RasterLink7 software (included) TxLink4 textile RIP (available) allow for unmatched productivity.

Other advanced features include dual motor take up for increased stability to prevent media walking

  • Drive motor mounted on the left and right sides: Distributes the load and strengthens winding force.
  • V-shape cut function: Fixes the tape at a single point straight against the paper core.
  • Dual motor take up: increased stability to reduce media walking
  • Cloth wiper: Increases removal of stray ink droplets on the nozzle.
  • Mimaki Remote Access (MRA): Allows machine operation via a smartphone or PC.

Our Core Technologies


Waveform Control


Variable Dot Technology


Mimaki Advanced Pass System


Mimaki Bulk Ink System


Uninterrupted Ink Supply System


Mimaki Fine Diffusion

Applications

img img img img img img img

Specifications

Printhead

One on-demand piezo head

Print resolution

300dpi, 600dpi, 900dpi, 1200dpi

Print speed (4 color mode)

up to 1453.1 SqFt/Hr (135.0 m2/h)

Maximum Print Area

63.4″ (1,610 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight

Roll weight: 45 kg or less (99.2 lbs)

Ink Type

Sublimation ink Sb411 (Bl, M, Y, K, Lbl, Lm, Lk), Sb410 (Fp, Fy)

Interface

Ethernet 1000 BASE-T / (USB2.0 Hi-speed)

Power Supply

Single-phase AC100-120 / 200-240V±10%, 50/60Hz±1Hz

Power Consumption

Max.: 1,440 W or less / Standard: 800 W

Operational Environment

Temperature: 20–30 °C (68–86 °F)
Humidity: 35–65% Rh (Non condensing)
Recommended temperature: 20–25 °C (68–77 °F)
Dust level: General office level

Dimensions (W × D × H)

3,170 x 820 x 1,305 mm (124.8 x 32.3 x 51.4″)

Weight

529.1 lbs (240 kg)

Certifications

VCCI class A, FCC class A, ETL IEC 62368-1,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, Energy Star, RCM, EAC, KC, UKCA

Inks

Dye Sublimation Ink (SB411, SB410)BlueMagentaYellowBlackLight BlueLight MagentaFluorescent YellowFluorescent Pink
2L MBIS Pack*S411-BLT-2LSB411-MT-2LSB411-YT-2LSB411-KT-2LSB411-LBT-2LSB411-LMT-2LSB410-FYT-2L-1-SWSB410-FPT-2L-1-SW
10 Kg TanksI-SB411-BLT-BJ-1-SWI-SB411-MT-BJ-1-SWI-SB411-YT-BJ-1-SWI-SB411-KT-BJ-1-SW

Inks

Dye Sublimation Ink (SB411, SB410)
2L MBIS Pack*
Blue:
S411-BLT-2L
Magenta:
SB411-MT-2L
Yellow:
SB411-YT-2L
Black:
SB411-KT-2L
Light Blue:
SB411-LBT-2L
Light Magenta:
SB411-LMT-2L
Fluorescent Yellow:
SB410-FYT-2L-1-SW
Fluorescent Pink:
SB410-FPT-2L-1-SW
:
_ _
:
_ _
10 Kg Tanks
Blue:
I-SB411-BLT-BJ-1-SW
Magenta:
I-SB411-MT-BJ-1-SW
Yellow:
I-SB411-YT-BJ-1-SW
Black:
I-SB411-KT-BJ-1-SW
