Ultimate Scalability For Continuous Long-Run Printing

The TS55-1800 dye-sublimation transfer printing system is the future of digital textile manufacturing and was created to empower designers. Effortlessly scale your operation with its high-end features that offer unattended continuous apparel/textile printing, industry-leading productivity, and low running costs to meet marketplace demands. This versatile transfer inkjet printer can provide a quick return on investment with unparalleled speeds for a high-volume textile printer, while low maintenance means less downtime.



Mimaki’s TS55-1800 digital fabric printer offers the following:
  • Maximum productivity of 1,453 SqFt/Hr
  • Mini jumbo roll that can support a paper length up to 8,202 feet
  • 22 lb ink supply, which reduces downtime and running costs
  • Extended heater options for increased ink drying capability (also prevents the medium from blocking)
  • “MAPS” functionality, which reduces banding by providing graduation to printed pass boundaries
  • Feed correction function by print mode; different values can be applied to each print mode, for less work and fast production
  • Dye-sublimation inks available in 4, 6 and 8 color configurations, including fluorescent pink and yellow
  • Inks hold ECO PASSPORT by Oeko-Tex® certification for safe and sustainable textile chemicals
  • Upgraded with the newest TxLink4 textile RIP software
  • RIP software RasterLink6 included

Our Core Technologies


Waveform Control


Variable Dot Technology


Mimaki Advanced Pass System


Nozzle Check Unit


Nozzle Recovery System


Mimaki Bulk Ink System


Mimaki Fine Diffusion

Applications

woman wearing one piece outfit with textile printed floral design printed display for skateboard decks modern decor showcasing the possibilities and applications of textile printing custom made curtains with textile printed design Custom printed wallpaper pattern custom exhibition and booth graphics soft-signage open house flag custom printed bicycle jersey
The TS55-1800 large format printer is capable of high-quality, high-volume printing at high speeds. It produces strong colors thanks to a dual CMYK system. In addition to apparel applications (the system helps create apparel for fashion and sports markets), this fabric printer can produce printed polyester for furniture, curtains, bedding, table cloths, and more. Users of this high-volume printer can expect a quick return on investment due to faster time to market in a range of paper sublimation applications.

Specifications

Printhead‎

Four in-line on-demand piezo heads

Print resolution

360 dpi, 480 dpi, 600 dpi, 540 dpi, 720 dpi, 1080 dpi, 1200 dpi

Print speed (4 color mode)

up to 1453.13 SqFt/Hr (135 m2/h)

Maximum Print Area

76.4″ (1940 mm)

Maximum media width‏

76.8″ (1950 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight 

99.2, 220.5, 661.4 lbs. (45, 100, 300 kg)

Ink Type

U.S. & Canada – Sb610 | Mexico, Central & South America- Sb610

Interface

Ethernet 1000BASE-T, USB2.0 Hi-speed

Power Supply⁢

Single phase AC 100-120 V/AC 200-240 V x1
Mini Jumbo Unit: Single phase AC 200-240 V x1
Extended Heater: Single phase AC100-120 V/AC AC 200-240 V ± 10%

Power Consumption

(AC 100 V) 1.44kW (AC 200 V) 1.92kW or less
Mini Jumbo Unit: (AC 200 V) 1.0 kW or less
Extended Heater: (AC 100 V) 1.0kW or less / (AC 200 V) 1.0kW or less

Operational Environment

Temperature 68° – 77° F (20-13.9° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

127.5″ x 28″ x 73.1″ (323.9 x 71.1 x 185.7 cm)

Weight

Main unit: 445.3 lbs. (202 kg)
Mini Jumbo Unit: 421.1 lbs. (191 kg)
10kg Ink supply unit: 77.2 lbs. (35 kg)
Extended heater: 33.1 lbs. (15 kg)

Dye Sublimation Ink (SB610)BlueMagentaYellowBlackLight BlueLight MagentaLight BlackFluorescent PinkFluorescent Yellow
2L Ink PackSB610-BLT-2LSB610-MT-2LSB610-YT-2LSB610-KT-2LSB610-LBT-2LSB610-LMT-2LSB610-LKT-2LSB610-FPT-2LSB610-FYT-2L
10 Kg (22 lbs.) TankSB610-BLT-BJSB610-MT-BJSB610-YT-BJSB610-KT-BJSB610-LBT-BJSB610-LMT-BJ

Dye Sublimation Ink (SB610)
2L Ink Pack
Blue:
SB610-BLT-2L
Magenta:
SB610-MT-2L
Yellow:
SB610-YT-2L
Black:
SB610-KT-2L
Light Blue:
SB610-LBT-2L
Light Magenta:
SB610-LMT-2L
Light Black:
SB610-LKT-2L
Fluorescent Pink:
SB610-FPT-2L
Fluorescent Yellow:
SB610-FYT-2L
:
_ _
10 Kg (22 lbs.) Tank
Blue:
SB610-BLT-BJ
Magenta:
SB610-MT-BJ
Yellow:
SB610-YT-BJ
Black:
SB610-KT-BJ
Light Blue:
SB610-LBT-BJ
Light Magenta:
SB610-LMT-BJ
:
_ _
:
_ _
:
_ _
:
_ _
Contact Mimaki
At Mimaki, you’ll find a wide range of roll-to-roll and dye-sublimation printing systems. For more information on the TS55-1800 digital fabric printer and to schedule a demo of our versatile industrial printer, call 888-530-3988 today.
