List Price (USD):
Valid in USA and Canada only
UJV100-160Plus: $14,995

Productivity And Versatility At An Entry-Level Price

The UJV100-160Plus is a competitively priced UV-LED roll-based printer with many productivity features found in higher-end models. It features Mimaki instant-dry UV-LED inks that adhere to a variety of media including paper, PET film, fabric, vinyl, and more -making post-printing handling and finishing effortless. With UV-LED lamps, the inks cure instantly, dramatically increasing printing speed and efficiency. This multi-purpose machine is suited for a variety of applications while keeping costs low.
  • Backlit applications utilizing Multiple-layer prints
  • New features allow for the reduction of ink consumption by up to 50% while maintaining the color balance of the original design.
  • Instantly cured prints for shorter turnaround time and no waiting to laminate.
  • With a maximum power consumption of 0.5kW, the UJV100-160Plus consumes less than 20% the power of eco-solvent and latex printers in the market (approximately)
  • Eco-friendly UV-LED six color ink set in 1-liter bottles: C, M, Y, K, White, Clear
  • Dot Adjustment System (DAS) automates dot position and feeding corrections, reducing manual intervention and workflow interruptions.

Our Core Technologies


Mimaki Advanced Pass System (MAPS)


Nozzle Recovery System


Nozzle Check Unit

Applications

img img img img img img img img

Specifications

Printhead

Two on-demand piezo heads, staggered layout

Print Resolutions

360 dpi, 720 dpi, 900 dpi, 1200 dpi

Maximum Print Area

63.4″ (1610.0 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 1 mm

Maximum Media Weight

up to 45 kg

Ink Type

U.S. & Canada- LUS-170
Mexico, Central & South America-
LUS-210: C, M, Y, K, W, CI (Clear ink: availability TBC)
LUS-190 / C,M,Y,K,W,CL (Clear)

Ink Package Size

1L bottle

Interface

Ethernet 1000 BASE-T, USB2.0 Hi-Speed

Power Supply

AC100~120V/200~240V±10% 50/60Hz±1Hz

Operational Environment

Temperature 20° – 30°C
Humidity: 35 – 65 % RH (Non condensing)

Dimensions (W × D × H)

109.3 x 27.6 x 58.1″ (2775 x 700 x 1475 mm)

Weight

368.2 lb (167 kg)

Options

Ionizer / Level foot / Lift-up block

Inks

UV Curable Ink (LUS170)CyanMagentaYellowBlackWhiteClear
1L BottleLUS17-C-BALUS17-M-BALUS17-Y-BALUS17-K-BALUS17-W-BALUS17-CL-BA

UV Curable Ink (LUS210)CyanMagentaYellowBlackWhiteClear
1L BottleLUS21-C-BALUS21-M-BALUS21-Y-BALUS21-K-BALUS21-W-BALUS21-CL-BA

Inks

UV Curable Ink (LUS170)
1L Bottle
Cyan:
LUS17-C-BA
Magenta:
LUS17-M-BA
Yellow:
LUS17-Y-BA
Black:
LUS17-K-BA
White:
LUS17-W-BA
Clear:
LUS17-CL-BA
UV Curable Ink (LUS210)
1L Bottle
Cyan:
LUS21-C-BA
Magenta:
LUS21-M-BA
Yellow:
LUS21-Y-BA
Black:
LUS21-K-BA
White:
LUS21-W-BA
Clear:
LUS21-CL-BA

Contact Mimaki

Mimaki offers a full range of UV and other roll-to-roll printers, including the UJV100-160. Contact us at 888-530-3988 with any questions or to schedule your demo today.
