Waveform Control

Variable Dot Technology

Mimaki Advanced Pass System

Nozzle Recovery System

Mimaki Bulk Ink System
| Printhead | 8 heads (2 stagger x 4 in-lined) |
| Print resolution | 300dpi, 600dpi |
| Print Speed | Max: 5,920 ft2/h (550 m2/h) |
| Maximum Print width | 72.8″ (1,850 mm) |
| Maximum media width | 74.8″ (1,900mm) |
| Maximum Media Thickness* | 5.0mm or less |
| Maximum Media Weight | 661.4 lb or less (300kg) |
| Ink Type | Sublimation Transfer MLSb510 |
| Interface | Ethernet 10GBASE-T USB2.0 (Removable Disk) |
| Power Supply | 3 phase 380-514V ± 5%, 50 / 60 Hz 25A or less |
| Power Consumption | Max. operating: 15.0kW or less Standby: 1.0kW or less |
| Dimensions (W × D × H) | 209″ x 110″ x 75″ (5,300 mm x 2,800 mm x 1,900 mm) |
| Weight | 3, 572 lb. (1,620kg) |
| Certifications* | ETL compliant with IEC62368-1, CE marking (EMC Directive, Low Voltage Directive, Machinery Directive) CB certification / RoHS / REACH / RCM / |
| Dye Sublimation Ink (MLSb510) | Blue | Magenta | Yellow | Black |
|---|---|---|---|---|
| 10kg Ink tank | MLS51-BLT-BJ | MLS51-MT-BJ | MLS51-YT-BJ | MLS51-KT-BJ |
| Dye Sublimation Ink (MLSb510) | |
|---|---|
| 10kg Ink tank |
|
