List Price (USD):
Valid in USA and Canada only
UJF-6042 MKII E: $34,645
UJF-6042 MKII: $41,995

Mimaki UJF-6042 MkII e Delivers Improved Image Quality

The UJF-6042 MkII e is a flatbed UV inkjet printer that uses state-of-the-art technology to create high-quality prints with exceptional accuracy. Designed for efficient on-demand, direct-to-object printing, it leverages Mimaki’s latest technological advances, including MFD2 (half-toning) for more precise ink dot positioning. A staggered head configuration maintains productivity levels even when two layers of color and spot colors are printed simultaneously.



This small format flatbed printer integrates automatic maintenance features and stands out for many other reasons:
  • Print area of 16.5″ x 24″; up to 6” thick
  • Eco-friendly with low VOC, GREENGUARD Gold certified UV-LED inks
  • Prints on plastic, wood, metal, leather, glass, and other substrates
  • Mimaki Clear Control (MCC) produces smoother, cleaner clear effects
  • RIP software RasterLink7 with variable print functions included
  • Optional deodorizing unit removes odors in offices, stores, and other sensitive environments
This affordable UV printer also supports MDL commands to expand automation capabilities. From an external production system or peripheral device, you can control printers and automate workflows such as workpiece transfer. Mimaki’s proprietary Nozzle Check Unit, Nozzle Recovery System, and Mimaki Advanced Pass System functions are included, allowing for high-quality prints and stable output.

Our Core Technologies


Mimaki Fine Diffusion


Mimaki Advanced Pass System


Waveform Control


Nozzle Check Unit


Nozzle Recovery System


Mimaki Circulation Technology

Applications

custom made conference hall sign with braille product packaging with custom printed design on carton box ball point pens with custom printed logos custom printed trophies and awards house key custom phone case with printed floral design serial plate with printed label industrial pressure meter custom printed membrane switch panels glass bottle with cork that displays a graphic printed inside the bottle
The UJF-6042 MkII e supports a wide range of applications. While it’s suited for printing on business cards, paper packaging, wedding boards and other flat surfaces, this system works equally well as a UV cylindrical printer. It prints directly to items such as key chains, smartphone cases, and water bottles. From nameplates to switches to all types of promotional/novelty items such as pens, device chargers, and USB sticks, the system delivers high speeds and crisp detail every time.

Specifications

Printhead

Four on-demand piezo heads in a staggered array

Print Resolutions

Maximum: 1200 x 1200 dpi

Print Speed (4 Color Mode)

up to 7.1 min / bed SqFt/Hr (7.1 min / bed m2/h)

Maximum Print Area

23.6″ x 16.5″ (600 x 420 mm)

Maximum media width

24″ (610 mm)

Maximum Media Thickness

up to 6.02″ (153 mm)

Maximum Media Weight

17.1″ (8.0 kg)

Ink Type

U.S. & Canada- LH-100, LUS-120, LUS-150 | Mexico, Central & South America- LH-100, LUS-120, LUS-150

Interface

Ethernet 1000BASE-T USB2.0 Hi-speed

Power Supply

Single-phase AC100-240V, ±10%, 50/60Hz ±1Hz

Power Consumption

AC100V: 1,000W or less

Operational Environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

65.6″ x 50.8″ x 33.7″ (166.6 x 129 x 85.6 cm)

Weight

330.7 lbs. (150 kg)

Certifications

VCCI class A / FCC class A / ETL IEC 62368-1 /CE Marking (EMC, Low voltage, Machinery directive, and RoHS) / CB / REACH / Energy Star / EAC / RCM

UV curable ink (LH-100)CyanMagentaYellowBlackWhiteLight CyanLight MagentaClear
250ml BottleI-LH100-C-B2-1I-LH100-M-B2-1I-LH100-Y-B2-1I-LH100-K-B2-1I-LH100-W-B2-1I-LH100-LC-B2-1I-LH100-LM-B2-1I-LH100-CL-B2-1
1L BottleLH100-C-BALH100-M-BALH100-Y-BALH100-K-BALH100-W-BALH100-LC-BALH100-LM-BALH100-CL-BA

UV curable ink (LUS-120)CyanMagentaYellowBlackWhiteLight CyanLight MagentaClear
250ml BottleI-LUS12-C-B2-1I-LUS12-M-B2-1I-LUS12-Y-B2-1I-LUS12-K-B2-1I-LUS12-W-B2-1I-LUS12-LC-B2-1I-LUS12-LM-B2-1I-LUS12-CL-B2-1
1L BottleLUS12-C-BALUS12-M-BALUS12-Y-BALUS12-K-BALUS12-W-BALUS12-LC-BALUS12-LM-BALUS12-CL-BA

UV curable ink (LUS-150)CyanMagentaYellowBlackWhite
1L BottleLUS15-C-BALUS15-M-BALUS15-Y-BALUS15-K-BALUS15-W-BA

UV Primer (PR-200)Primer
250ml BottlePR200-Z-BA
1L BottlePR200-Z-BA

UV curable ink (LH-100)
250ml Bottle
Cyan:
I-LH100-C-B2-1
Magenta:
I-LH100-M-B2-1
Yellow:
I-LH100-Y-B2-1
Black:
I-LH100-K-B2-1
White:
I-LH100-W-B2-1
Light Cyan:
I-LH100-LC-B2-1
Light Magenta:
I-LH100-LM-B2-1
Clear:
I-LH100-CL-B2-1
:
_ _
:
_ _
1L Bottle
Cyan:
LH100-C-BA
Magenta:
LH100-M-BA
Yellow:
LH100-Y-BA
Black:
LH100-K-BA
White:
LH100-W-BA
Light Cyan:
LH100-LC-BA
Light Magenta:
LH100-LM-BA
Clear:
LH100-CL-BA
:
_ _
:
_ _
UV curable ink (LUS-120)
250ml Bottle
Cyan:
I-LUS12-C-B2-1
Magenta:
I-LUS12-M-B2-1
Yellow:
I-LUS12-Y-B2-1
Black:
I-LUS12-K-B2-1
White:
I-LUS12-W-B2-1
Light Cyan:
I-LUS12-LC-B2-1
Light Magenta:
I-LUS12-LM-B2-1
Clear:
I-LUS12-CL-B2-1
:
_ _
:
_ _
1L Bottle
Cyan:
LUS12-C-BA
Magenta:
LUS12-M-BA
Yellow:
LUS12-Y-BA
Black:
LUS12-K-BA
White:
LUS12-W-BA
Light Cyan:
LUS12-LC-BA
Light Magenta:
LUS12-LM-BA
Clear:
LUS12-CL-BA
:
_ _
:
_ _
UV curable ink (LUS-150)
1L Bottle
Cyan:
LUS15-C-BA
Magenta:
LUS15-M-BA
Yellow:
LUS15-Y-BA
Black:
LUS15-K-BA
White:
LUS15-W-BA
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
UV Primer (PR-200)
250ml Bottle
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
Primer:
PR200-Z-BA
1L Bottle
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
Primer:
PR200-Z-BA

Frequently Bought Together

Kebab for UJF Series Printers

The Kebab option for UJF Series offers 360-degree direct printing on a wide range of objects, such as stainless steel tumblers, bottles, cans, vases, packaging and candle holders. This accessory is easily mounted to the printer’s flatbed table and functions intuitively via our RasterLink6 software.

Kebab

Kebab for UJF Series Printers

This 3D machine, co-branded with Sindoh, utilizes fused filament fabrication technology to form three-dimensional objects.

3DFF-222
