Entry-Level Price, Professional Results

The TS100-1600 is an affordable professional grade sublimation roll-based printer. Consistently and expertly print highly detailed photographic quality graphics for small to large production runs.
  • Available in 64” with print speeds up to 753 Sq Ft/Hr
  • Nozzle Check Unit (NCU), automatically monitors printhead performance and detects clogged nozzles
  • Nozzle Recovery System (NRS), automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality
  • Sublimation ink colors: Blue, Magenta, Yellow and Black
  • NEW Dot Adjustment System (DAS) automatically aligns to ensure consistent quality and repeatability
  • NEW, easier to use RIP software, RasterLink7, included; reduces RIP time by 25%
  • TxLink4 Lite supported for more advanced workflows

Our Core Technologies


Waveform Control


Variable Dot Technology


Mimaki Advanced Pass System


Nozzle Check Unit


Nozzle Recovery System


Mimaki Bulk Ink System


Uninterrupted Ink Supply System


Mimaki Fine Diffusion


Mimaki Circulation Technology

Applications

Specifications

Printhead

Two staggered, on-demand piezo heads

Print resolution

360 dpi, 600 dpi, 720 dpi, 900 dpi

Print speed (4 color mode)

753 SqFt/Hr

Maximum Print Area

63.3″ (1610.0 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight⁨⁣

Up to 99.2 pounds (45 kg)

Ink Type

U.S. & Canada – Sb610 | Mexico, Central & South America- Sb610

Interface

1000 Base-T Ethernet cable or USB2.0 cable

Power Supply⁧⁢

AC100~120V/ 200~240V±10%, 50/60Hz±1Hz

Power Consumption

INLET 1/2: 1,440W or less (AC100V environment) 1,920W or less (AC200V environment)

Operational Environment

Temperature 20° – 30°C
Humidity: 35 – 65 % RH (Non condensing)

Dimensions (W × D × H)

109.3 x 27.6 x 58.1″ (2,775 x 700 x 1,475 mm)

Weight

366lb (166kg)

Certifications

VCCI class A, FCC class A,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, ENERGY STAR®, RCM, EAC

Dye Sublimation Ink (SB610)BlueMagentaYellowBlack
1L BottlesI-SB610-BLT-BA-1-SW (E)I-SB610-MT-BA-1-SW (E)I-SB610-YT-BA-1-SW (E)I-SB610-KT-BA-1-SW (E)

Dye Sublimation Ink (SB610)
1L Bottles
Blue:
I-SB610-BLT-BA-1-SW (E)
Magenta:
I-SB610-MT-BA-1-SW (E)
Yellow:
I-SB610-YT-BA-1-SW (E)
Black:
I-SB610-KT-BA-1-SW (E)
