List Price (USD):
Valid in USA and Canada only
UJ330H-160: $39,995

The Next Evolution in Mimaki Wide Format Innovation

Being competitive requires staying ahead. Introducing the new Mimaki UJ330H 160—the most advanced Mimaki hybrid printer ever. Engineered to expand your possibilities, it seamlessly handles an exceptional range of roll and rigid media, giving you the freedom to take on more jobs with confidence. Powered by Mimaki’s proven 330 series print engine, the UJ330H 160 delivers the perfect balance of speed and precision. Its dual printheads and 6 color configuration offer flexible setups, including - x2 CMYK or CMYK + Clear + White, or CMYK + Light Cyan + Light Magenta + White. Designed for versatility, the printer features a generous 2-inch (50.8 mm) head clearance and an innovative vacuum transport belt system that eliminates pinch rollers - minimizing marks and enabling smooth, accurate printing on even the thinnest media. With resolutions up to 1200 × 1800 dpi and Mimaki’s complete suite of core technologies - NCU, NRS, DAS2, VDT, MWDT, MAPS4, and Mimaki PICT—you gain smarter automation, consistent performance, and the power to monitor everything from ink usage to production status right from your phone. Capable of 5 layer and 2.5D texture printing, the UJ330H 160 delivers a truly robust, intuitive hybrid experience. It’s the all in one printing solution built to elevate quality, expand capability, and keep your business ahead of the competition.
  • Dual-Media Versatility in a Single Footprint: The UJ330H-160 allows users to switch between rigid and roll-to-roll applications in minutes, enabling the production of everything from window graphics and vehicle wraps to 4×11-foot aluminum composite signs on one machine.
  • Innovative Belt Transport System: Unlike conventional methods, the newly developed belt conveyor system provides stable, consistent transport for thin films and fabrics, effectively suppressing the wrinkles and loosening that other printers experience, for high-quality exhibition and retail signage.
  • Heavy-Duty Rigid Media Support: Equipped with Auto-Vacuum and front/rear lock rollers, the printer can handle large and heavy materials, including 2-in thick board and standard signboard materials like aluminum composite plates.
  • High-Value Specialty Printing: The printer supports multilayered printing (up to five layers), textured embossing effects, and gloss or matte finishes using clear ink, allowing shops to offer premium, high-margin products.
  • Flagship Image Quality & Productivity: As part of the 330 Series, it delivers industry-leading image quality with a high throughput of 22.0 sqm/hr, ensuring high-definition graphics and smooth gradients that capture customer attention.
  • Space and Cost Efficiency: By consolidating two functions into one unit, customers can maximize limited floor space and reduce capital investment costs compared to purchasing separate dedicated flatbed and roll-to-roll printers.
  • User-Friendly Automation: Advanced automatic adjustment functions allow operators to maintain optimal conditions and consistent quality without needing specialized skills, reducing training requirements and the likelihood of operator error.
  • Safe and Environmentally Conscious: The UV inks are designed to be free of SVHC and CMR substances, ensuring a safer workplace for operators and compliance with global environmental regulations.
  • LamiFit Technology: Mimaki’s Innovative solution to board lamination “Silvering” problem. LamiFit will fill the blank areas of the print with clear ink to keep the media topography level to negate trapped air bubbles during lamination.
  • Eco Friendly power Solution: Total maximum power usage is only 1.6kW compared to Latex at 5Kw and Eco-Solvent at 2.9kW.

Our Core Technologies


Waveform Control


Mimaki Advanced Pass System


Nozzle Check Unit


Nozzle Recovery System


Mimaki Bulk Ink System


Uninterrupted Ink Supply System


Mimaki Circulation Technology


Mimaki Fine Diffusion

Applications

img img img img img img img img

Specifications

Print head

2 heads (staggered) 4 print bars per head

Print Resolutions

Y : 600, 1200 dpi X : 600, 900, 1200, 1800 dpi

Print Speed (4 Color Mode)

236.8 sqft/hr, (22.0 sqm/hr,) max

Maximum Print Width or Maximum Print Area

Rigid – 4ft x 11ft

Maximum Media Width or Maximum Media Size

Roll – 64 in (1620mm)

Maximum Media Thickness

up to 2 in (50 mm)

Maximum Media Weight

Rigid – up to 55lbs (25 KG)  Roll – up to 99lbs (45Kg)

Ink Type

ELS-170 & ELS-175* – CMYK-KYMC / CMKY +Cl +WW / CMYK +Lm +Lc +WW

*LUS-210 – CCMMYYKK / CCMMYK +WW (*only sold in certain countries)

Ink Package siz

1 ltr

Interface

(Recommended) Ethernet 1000BASE-T USB 2.0 Hi-Speed

Power Supply

AC (100–120V / 200–240V ±10%) ×2, 50/60Hz ±1Hz

Power Consumption

Maximum – 1600W

Average during operation 800W

Sleep mode 4.5W or less

Operational Environment

Temperature:  68˚ to 86˚ / F (20˚ to 30 C)

Humidity:  35% to 65%

Dimensions (W × D × H)

W126.9″x D30.9″x H55.9″  / 3,225mm x 785mm x 1,420mm (without tables)

W126.9×D104.9×H55.9” / 3,225mm×2,664mm×1,420mm (with one set of tables)

W126.9×D185.5×H55.9”) / 3,225mm×4,712mm×1,420mm / (with two sets of tables )

Weight

849 lbs. (386 kg)

Certifications

Compliant with 62368-1, IEC
CB、CE(EMC, Low voltage, Machinery directive, and RoHS)
REACH、VCCI Class A、FCC Class A
KC、RCM、EAC, UKCA、EnergyStar

Inks

UV Curable Ink (ELS-170)CyanMagentaYellowBlackLight CyanLight MagentaWhiteClear
1L BottleLUS170-C-BALUS170-M-BALUS170-Y-BALUS170-K-BALUS170-LC-BALUS170-LM-BALUS170-W-BALUS170-CL-BA

UV Curable Ink (ELS-175) *LATAM Market OnlyCyanMagentaYellowBlackLight CyanLight MagentaWhiteClear
1L BottleLUS175-C-BALUS175-M-BALUS175-Y-BALUS175-K-BALUS175-LC-BALUS175-LM-BALUS175-W-BALUS175-CL-BA

UV Curable Ink (LUS-210) *LATAM Market OnlyCyanMagentaYellowBlackWhite
1L BottleLUS210-C-BALUS210-M-BALUS210-Y-BALUS210-K-BALUS210-W-BA

Inks

UV Curable Ink (ELS-170)
1L Bottle
Cyan:
LUS170-C-BA
Magenta:
LUS170-M-BA
Yellow:
LUS170-Y-BA
Black:
LUS170-K-BA
Light Cyan:
LUS170-LC-BA
Light Magenta:
LUS170-LM-BA
White:
LUS170-W-BA
Clear:
LUS170-CL-BA
UV Curable Ink (ELS-175) *LATAM Market Only
1L Bottle
Cyan:
LUS175-C-BA
Magenta:
LUS175-M-BA
Yellow:
LUS175-Y-BA
Black:
LUS175-K-BA
Light Cyan:
LUS175-LC-BA
Light Magenta:
LUS175-LM-BA
White:
LUS175-W-BA
Clear:
LUS175-CL-BA
UV Curable Ink (LUS-210) *LATAM Market Only
1L Bottle
Cyan:
LUS210-C-BA
Magenta:
LUS210-M-BA
Yellow:
LUS210-Y-BA
Black:
LUS210-K-BA
White:
LUS210-W-BA
