Enhanced quality and high-speed performance

This inkjet printer offers reliable print technologies in a compact design and at an affordable price, allowing print shops to create either sign and graphic applications (durable banners, signs, posters, etc) or textile and apparel runs. Compatible with solvent and dye sublimation inks, this entry-level wide format printer is designed for stability and performance.
  • Maximum print speed of 17.5 m 2 /h with 4 colors, 9 m 2 /h with 6 colors
  • Compatible with dye sublimation and solvent inks
  • Available solvent ink in White and Silver for increased value added applications
  • Easy media set up and media cutter for enhanced user-friendliness

Our Core Technologies


Uninterrupted Ink Supply System (UISS)


Variable Dot Technology


Mimaki Bulk Ink System (MBIS)


Mimaki Intelligent Heaters (MIH)


Mimaki Advanced Pass System (MAPS)

Applications

Specifications

Printhead

One on-demand piezo head

Print Resolutions

540dpi, 720 dpi, 1,080dpi

Print Speed (4 Color Mode)

up to 211.0 SqFt/Hr (19.6 m2/h)

Maximum Print Area

63.4″ (1610.0 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 0.0″ (1.0 mm)

Maximum Media Weight

55.1 lbs. (25.0 kg)

Ink Type

U.S. & Canada- n/a | Mexico, Central & South America- Sb53, Sb54, SS21, ES3

Interface

USB2.0 Hi-speed

Power Supply

Single phase AC100 – 120V / AC220 – 240V ±10%

Power Consumption

AC100V: 1440W or less

Operational Environment

Temperature 64° – 95° F (17.8-35° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

143.7 x 51.3 x 56.1″ (365.0 x 130.2 x 142.4 cm)

Weight

319.7 lbs. (145 kg)

Certifications

VCCI class A / UL60950-1 / FCC class A / CE Marking (EMC and Low voltage directive) / CB report

Solvent Ink (SS21)CyanMagentaYellowBlackLight CyanLight MagentaWhite
440ml cartridgeSPC-0501CSPC-0501MSPC-0501YSPC-0501KSPC-0501LCSPC-0501LMSPC-0504W-2
2L Ink PackSPC-0588CSPC-0588MSPC-0588YSPC-0588KSPC-0588LCSPC-0588LM

Eco Solvent Ink (ES3)CyanMagentaYellowBlackLight CyanLight MagentaWhiteSilver
440ml cartridgeSPC-0440CSPC-0440MSPC-0440YSPC-0440KSPC-0440LCSPC-0440LMSPC-0433W-2SPC-0433Si

Dye Sublimation Ink (Sb54)BlueMagentaYellowBlackLight BlueLight Magenta
2L MBIS Pack*SB54-BLT-2LSB54-MT-2LSB54-YT-2LSB54-KT-2LSB54-LBT-2LSB54-LMT-2L
440ml cartridgeSB54-BLT-44SB54-M-44SB54-Y-44SB54-K-44SB54-LBL-44SB54-LMT-44

Dye Sublimation Ink (Sb53)BlueMagentaYellowBlackLight BlueLight Magenta
2L MBIS Pack*SB53-BL-2LSB53-ML-2LSB53-Y-2LSB53-K-2LSB53-LBL-2LSB53-LM-2L
440ml cartridgeSB53-BL-44SB53-M-44SB53-Y-44SB53-K-44SB53-LBL-44SB53-LM-44

Solvent Ink (SS21)
440ml cartridge
Cyan:
SPC-0501C
Magenta:
SPC-0501M
Yellow:
SPC-0501Y
Black:
SPC-0501K
Light Cyan:
SPC-0501LC
Light Magenta:
SPC-0501LM
White:
SPC-0504W-2
2L Ink Pack
Cyan:
SPC-0588C
Magenta:
SPC-0588M
Yellow:
SPC-0588Y
Black:
SPC-0588K
Light Cyan:
SPC-0588LC
Light Magenta:
SPC-0588LM
White:
_ _
Eco Solvent Ink (ES3)
440ml cartridge
Cyan:
SPC-0440C
Magenta:
SPC-0440M
Yellow:
SPC-0440Y
Black:
SPC-0440K
Light Cyan:
SPC-0440LC
Light Magenta:
SPC-0440LM
White:
SPC-0433W-2
Silver:
SPC-0433Si
Dye Sublimation Ink (Sb54)
2L MBIS Pack*
Blue:
SB54-BLT-2L
Magenta:
SB54-MT-2L
Yellow:
SB54-YT-2L
Black:
SB54-KT-2L
Light Blue:
SB54-LBT-2L
Light Magenta:
SB54-LMT-2L
440ml cartridge
Blue:
SB54-BLT-44
Magenta:
SB54-M-44
Yellow:
SB54-Y-44
Black:
SB54-K-44
Light Blue:
SB54-LBL-44
Light Magenta:
SB54-LMT-44
Dye Sublimation Ink (Sb53)
2L MBIS Pack*
Blue:
SB53-BL-2L
Magenta:
SB53-ML-2L
Yellow:
SB53-Y-2L
Black:
SB53-K-2L
Light Blue:
SB53-LBL-2L
Light Magenta:
SB53-LM-2L
440ml cartridge
Blue:
SB53-BL-44
Magenta:
SB53-M-44
Yellow:
SB53-Y-44
Black:
SB53-K-44
Light Blue:
SB53-LBL-44
Light Magenta:
SB53-LM-44

Resources

Specifications

JV33-160
