Waveform Control
Variable Dot Technology
Mimaki Advanced Pass System
Nozzle Recovery System
Mimaki Bulk Ink System
Mimaki Circulation Technology
Mimaki Fine Diffusion
| Printhead | Sixteen on-demand piezo heads in a staggered array |
| Print Resolutions | 600 x 600dpi, 600 x 1,200dpi, 1,200 x 1,200dpi |
| Print Speed (4 Color Mode) | up to 2,152.78 SqFt/Hr (200.0 m2/h) |
| Maximum Print Area | 98.43″ x 51.18″ (2,500 x 1,300 mm) |
| Maximum media area | up to 101.6” x 80.3” |
| Maximum Media Thickness | up to 2.36″ (60 mm) |
| Maximum Media Weight | 110.2 lbs. (50kg/m²) |
| Ink Type | Rigid: LH-100, Flexible: LUS-120, LUS-150 |
| Interface | Ethernet 10,000 BASE-T |
| Power Supply | AC 200 – 240 V, 50/60 Hz |
| Power Consumption | x3 AC200-240±10% ~16kVA 50/60Hz±1Hz |
| Operational Environment | Temperature 68° – 86° F (15-30° C) |
| Dimensions (W × D × H) | 207.48″ x 110.24″ x 62.99″ (5,300×2,850×1,700mm) |
| Weight | 2, 645.5 lbs. (1,200 kg) |
| Certifications | UL 775 ETL, CE Marking (EMC Directive,Low Voltage Directive, Machinery Directive), RoHS / REACH / EAC |
| LH-100 UV curable ink | Cyan | Magenta | Yellow | Black | White | Clear | Primer | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | LH100-C-BA | LH100-M-BA | LH100-Y-BA | LH100-K-BA | LH100-W-BA | LH100-CL-BA |
| UV curable ink (LUS-120) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | White | Clear | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | LUS12-C-BA | LUS12-M-BA | LUS12-Y-BA | LUS12-K-BA | LUS12-W-BA | LUS12-CL-BA |
| UV curable ink (LUS-150) | Cyan | Magenta | Yellow | Black | White | Clear | Primer | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | LUS15-C-BA | LUS15-M-BA | LUS15-Y-BA | LUS15-K-BA | LUS15-W-BA | (Use LH-100) |
| UV Primer (PR-200) | Primer | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | PR200-Z-BA |
| LH-100 UV curable ink | |
|---|---|
| 1L Bottle |
|
| UV curable ink (LUS-120) | |
|---|---|
| 1L Bottle |
|
| UV curable ink (LUS-150) | |
|---|---|
| 1L Bottle |
|
| UV Primer (PR-200) | |
|---|---|
| 1L Bottle |
|
