Achieve maximum productivity with minimal steps

This series delivers an array of applications to optimize workflows. Equipped with innovative technologies for faster throughput and on-board cutting, you can create indoor and outdoor graphics using eco-solvent inks or textile, apparel and soft signage using dye-sublimation inks.
  • Available in 54” and 64” widths with print speeds up to 1,140 SqFt/Hr
  • Print and cut capability in one unit
  • Ability to pre-cut before printing to prevent film separation
  • Choice of eco-solvent ink or dye-sublimation ink sets:

Eco-solvent: 10 color options including Silver, White, Orange and Light Black inks

Dye-sublimation: 6 color options including Light Blue and Light Magenta inks



  • ID Cut Function for automation and unattended operation
  • Optional economical 2-liter bulk ink system for long running jobs
  • Even ink drying with three-way intelligent heater
  • Reusable Mimaki Eco-Cartridge on SS21, BS3 and BS4 eco-solvent inks
  • Automatic media take-up reel
  • USB/Ethernet connectivity
  • RIP software RasterLink6 included

Our Core Technologies


Waveform Control


Mimaki Advanced Pass System


Intelligent Heaters


Nozzle Check Unit


Nozzle Recovery System


Mimaki Bulk Ink System


Uninterrupted Ink Supply System


Mimaki Circulation Technology


Mimaki Fine Diffusion


Continuous Mark Detect


Half Cut


Over Cut


Zero Margin Mark

Applications

Specifications

Printhead

Two on-demand piezo heads in a staggered array

Print resolution

360 dpi, 540 dpi, 720 dpi, 1,080 dpi, 1,440 dpi

Print speed (4 color mode)

CJV300-130 Plus: up to 991.4 SqFt/Hr (92.1 m2/h)
CJV300-160 Plus: up to 1,139.9 SqFt/Hr (105.9 m2/h)

Maximum print width

CJV300-130 Plus: 53.6″ (1,361 mm)
CJV300-160 Plus: 63.4″ (1,610 mm)

Maximum media width

CJV300-130 Plus: 54″ (1,371 mm)
CJV300-160 Plus: 63.8″ (1,620 mm)

Maximum media thickness

up to .04″ (1 mm)

Maximum media weight

99 lbs. (45 kg)

Ink Type/Color

US & Canada- SS21, ES3, Sb54 | Mexico, Central & South America- SS21, ES3, BS3, BS4, Sb54

Cut Speed

11.8″ sec (30 cm/sec)

Maximum Cut pressure (Metric grams)

450

Cutter Types

Eccentric cutter, Blade for small character, Blade for reflective sheet,
Blade for fluorescent sheet, Blade for PVC with low-pressure, Ball point pen

Interface

Ethernet, USB 2.0

Power supply

Single phase (AC100-120 / 200-240V±10%, 50/60Hz±1Hz) x2

Power consumption

AC100V: 1.44kW or less x2 | AC200V: 1.92kW or less x2

Operational environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

CJV300-130 Plus: 99″ x 28″ x 55″ (251.5 x 71.1 x 139.7 cm)
CJV300-160 Plus: 109″ x 28″ x 55″ (276.9 x 71.1 x 139.7 cm)

Weight

CJV300-130 Plus: 368 lbs. (167 kg)
CJV300-160 Plus: 392 lbs. (178 kg)

Certifications

VCCI class A, FCC class A, Compliant with UL 60950-1, ETL, CE Marking (EMC, Low voltage, and Machinery directive) /RoHS/ CB Report, REACH, ENERGY STAR®, RCM

Eco Solvent ink (SS21)CyanMagentaYellowBlackLight CyanLight MagentaLight BlackOrangeWhiteSilver
2L MBIS Pack*SPC-0588CSPC-0588MSPC-0588YSPC-0588KSPC-0588LCSPC-0588LMSPC-0588LKSPC-0588OR
220ml cartridgeSPC-0504W-2SPC-0504Si
600ml eco cartridgeSS21-C-60SS21-M-60SS21-Y-60SS21-K-60SS21-LC-60SS21-LM-60SS21-LK-60SS21-OR-60

Eco Solvent ink (ES3)CyanMagentaYellowBlackLight CyanLight MagentaWhite
440ml cartridgeSPC-0440CSPC-0440MSPC-0440YSPC-0440KSPC-0440LCSPC-0440LM
220ml cartridgeSPC-0433W-2

Dye Sublimation ink (Sb54)BlueMagentaYellowBlackLight BlueLight Magenta
2L MBIS Pack*SB54-BLT-2LSB54-MT-2LSB54-YT-2LSB54-KT-2LSB54-LBT-2LSB54-LMT-2L
440ml cartridgeSB54-BLT-44SB54-M-44SB54-Y-44SB54-K-44SB54-LBL-44SB54-LMT-44

Solvent ink (BS3)CyanMagentaYellowBlack
2L MBIS Pack*SPC-0693CSPC-0693MSPC-0693YSPC-0693K
600ml eco cartridgeSPC-0667CSPC-0667MSPC-0667YSPC-0667K

Solvent ink (BS4)CyanMagentaYellowBlack
2L MBIS Pack*BS4-C-2LBS4-M-2LBS4-Y-2LBS4-K-2L
600ml eco cartridgeBS4-C-60BS4-M-60BS4-Y-60BS4-K-60

*Inks sold vary by county, see specification chart above for details.

Eco Solvent ink (SS21)
2L MBIS Pack*
Cyan:
SPC-0588C
Magenta:
SPC-0588M
Yellow:
SPC-0588Y
Black:
SPC-0588K
Light Cyan :
SPC-0588LC
Light Magenta :
SPC-0588LM
Light Black :
SPC-0588LK
Orange:
SPC-0588OR
:
:
_ _
220ml cartridge
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
White:
SPC-0504W-2
Silver:
SPC-0504Si
600ml eco cartridge
Cyan:
SS21-C-60
Magenta:
SS21-M-60
Yellow:
SS21-Y-60
Black:
SS21-K-60
Light Cyan:
SS21-LC-60
Light Magenta:
SS21-LM-60
Light Black:
SS21-LK-60
Orange:
SS21-OR-60
:
_ _
:
_ _
Eco Solvent ink (ES3)
440ml cartridge
Cyan:
SPC-0440C
Magenta:
SPC-0440M
Yellow:
SPC-0440Y
Black:
SPC-0440K
Light Cyan :
SPC-0440LC
Light Magenta :
SPC-0440LM
:
_ _
:
_ _
:
_ _
:
_ _
220ml cartridge
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
White:
SPC-0433W-2
:
_ _
Dye Sublimation ink (Sb54)
2L MBIS Pack*
Cyan:
SB54-BLT-2L
Magenta:
SB54-MT-2L
Yellow:
SB54-YT-2L
Black:
SB54-KT-2L
Light Blue:
SB54-LBT-2L
Light Magenta:
SB54-LMT-2L
:
_ _
:
_ _
:
_ _
:
_ _
440ml cartridge
Cyan:
SB54-BLT-44
Magenta:
SB54-M-44
Yellow:
SB54-Y-44
Black:
SB54-K-44
Light Blue:
SB54-LBL-44
Light Magenta:
SB54-LMT-44
:
_ _
:
_ _
:
_ _
:
_ _
Solvent ink (BS3)
2L MBIS Pack*
Cyan:
SPC-0693C
Magenta:
SPC-0693M
Yellow:
SPC-0693Y
Black:
SPC-0693K
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
600ml eco cartridge
Cyan:
SPC-0667C
Magenta:
SPC-0667M
Yellow:
SPC-0667Y
Black:
SPC-0667K
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
Solvent ink (BS4)
2L MBIS Pack*
Cyan:
BS4-C-2L
Magenta:
BS4-M-2L
Yellow:
BS4-Y-2L
Black:
BS4-K-2L
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
600ml eco cartridge
Cyan:
BS4-C-60
Magenta:
BS4-M-60
Yellow:
BS4-Y-60
Black:
BS4-K-60
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
:
_ _
*Inks sold vary by county, see specification chart above for details.
